Road Bikes BH Quartz SL 1.5 Shimano 105 11V 700 mm Red
BH
Color : Red
+ 1 Color
Description
What size do you need?
Choosing the right sized bike depends on the type of bike, your height, your riding style, and your preference. A correct fitting bike will be more comfortable, more efficient and more fun to ride
Measure yourself accurately
To get started, measure your height and use the size chart available on each product description.
What to do if you are in between bike sizes?
If you are on the edge of two different bike sizes, don't worry, you'll probably be ok on either size (rather than thinking that one size will be awful and the other will fit). Indeed, bikes are adjustable: the seatpost can slide up and down, the saddle can move backwards and forwards and you can even switch out parts like the stem for different sized ones to help the bike fit better.
Finding out whether or not you should pick a bigger or a smaller frame is sometimes as simple as personal preference, but there are a few simple ways to work out which might suit best:
- If you’re flexible, you might prefer a shorter head tube, so the smaller size might work out better for you. You can use a longer stem to make the reach more comfortable.
- On a bigger bike, the reach to the handlebars will be longer. This means that if you have proportionally longer arms, you might be more comfortable on a bigger frame.
Still confused? Contact us
| Please note that specifications are subject to change without notice, based on component availability and other factors. |
The Quartz SL range is ideal for those who want to discover the world of road biking without breaking the bank, while retaining the values of comfort, dynamism and freedom.
Designed in 7005 aluminum, with hydroformed tubes that offer a highly polished endurance aesthetic for covering the kilometers, without limits. Polished welds further refine the Quartz SL frame.
The geometry has also been optimized: while retaining the very essence of BH frames, the comfort of the bike has been studied for each rider. Available in four sizes. It features integrated thru-axle locks and the Flat Mount disc braking system.
The carbon fork reduces weight and improves riding comfort, while dissipating road vibrations.
The 12 mm thru-axle offers the optimum characteristics for increased rigidity and safety, while optimizing the position of the disc brake, without the need for tools when the rider has to dismount the wheel.
Product highlights :
- Aluminum frame and carbon fork.
- Shimano 105 2x11-speed transmission.
- Shimano 105 hydraulic disc brakes.
Details :
| Frame | Aluminum: Quartz disc aluminum 6061, thru axle 12mm |
| Fork | Carbon: Quartz disc, 1.5" integrated carbon |
| Derailleur | Shimano 105 2x1 speed |
| Front derailleur | Shimano 105 |
| Rear derailleur | Shimano 105 11 speed |
| Cassette | Shimano 105 11/34 teeth |
| Chain | FSA TH-CN1102 |
| Crankset | FSA Vero Pro 46/36 teeth |
| Brakes | Shimano 105 hydraulic |
| Wheels | Shimano RS170 |
| Tires | Hutchinson nitro2 700x28 |
| Handlebars | BH Lite Compact |
| Headset | FSA ICR |
| Seat clamp | SL1 integrated |
| Saddle | San Marco Monza Start |
| Seat post | BH Lite 27.2 |
| Reference | LD153 |
Geometries :
| Frame size | XS | S | M | L | XL |
| Seat tube (mm) | 480 | 500 | 520 | 540 | 560 |
| Top tube (mm) | 530 | 543 | 557 | 570 | 583 |
| Base length (mm) | 428 | 428 | 428 | 428 | 428 |
| Steering bushing (mm) | 115 | 140 | 165 | 185 | 200 |
| Steering angle (°) | 72.5 | 72.5 | 73 | 73 | 73 |
| Seat tube angle (°) | 74 | 74 | 73 | 72.5 | 72.5 |
| Satck (mm) | 530 | 551 | 560 | 587 | 596 |
| Reach (mm) | 381 | 387 | 389 | 398 | 404 |
MORE INFORMATION
See all our Road bikes.
Features
| Manufacturer Weight (g) | 9400 |
| Gender |
Men Women |
| Wheel Size | 700mm |
| Groupset | Shimano 105 |
