Gravel bike BH Gravel X Alu 2.0 Shimano GRX 12V 700 mm Green
BH
★★★★★
★★★★★
Color : Green
+ 2 Colors
Description
What size do you need?
Choosing the right sized bike depends on the type of bike, your height, your riding style, and your preference. A correct fitting bike will be more comfortable, more efficient and more fun to ride
Measure yourself accurately
To get started, measure your height and use the size chart available on each product description.
What to do if you are in between bike sizes?
If you are on the edge of two different bike sizes, don't worry, you'll probably be ok on either size (rather than thinking that one size will be awful and the other will fit). Indeed, bikes are adjustable: the seatpost can slide up and down, the saddle can move backwards and forwards and you can even switch out parts like the stem for different sized ones to help the bike fit better.
Finding out whether or not you should pick a bigger or a smaller frame is sometimes as simple as personal preference, but there are a few simple ways to work out which might suit best:
- If you’re flexible, you might prefer a shorter head tube, so the smaller size might work out better for you. You can use a longer stem to make the reach more comfortable.
- On a bigger bike, the reach to the handlebars will be longer. This means that if you have proportionally longer arms, you might be more comfortable on a bigger frame.
Still confused? Contact us
| Please note that specifications are subject to change without notice, based on component availability and other factors. |
When we designed the Gravel X, our goal was clear: to create a comfortable bike that could cover kilometers and kilometers of varied terrain.
The Shimano GRX 12V features a 42mm wheel arch for Tyres, the ideal size for greater rigidity and safety, while optimizing the position of the brake. With 12mm thru axles for added rigidity and safety, the disc brakes fitted to the GravelX are the perfect accompaniment to both wheels.
Ride comfort and stability, high head tube and long wheelbase. The geometry of the GravelX has focused on ride comfort and stability for long hours of riding. These virtues are underpinned by a high head tube, a slooping top tube with restrained measurements and a long wheelbase.
The frame's rear end and Fork have been totally redesigned to withstand the stresses and strains produced by the 140/160 mm disc brakes.
The Gravel X lets you get away from traffic without losing the feeling of speeding along, or simply getting lost in your expeditions while contemplating the surrounding landscape.
Product highlights:
- Aluminum Frame and carbon Fork.
- Shimano GRX transmission, 1x12 speeds.
- Shimano hydraulic disc brakes.
Details :
| Frame | Aluminum: Gravel X Alloy 7005 Hydroforming |
| Fork | Carbon: Gravel X Carbon 1.5 |
| Derailleur lever | Shimano GRX, 1x12 speeds |
| Rear derailleur | Shimano GRX 12-speed |
| Cassette | Shimano 105 11/36 teeth |
| Chain | Shimano 105 |
| Crankset | Shimano GRX Mono 40 teeth |
| Brakes | Shimano Disc hydraulic |
| Wheels | Shimano RS171 Disc |
| Tyres | Hutchinson Overide 700x38 |
| Handlebars | BH Lite Gravel |
| Stem | BH SL |
| Headset | BH SL integrated sealed bearing |
| Saddle clamp | BH Gravel X |
| Saddle | San Marco Monza Start |
| Seat post | BH Lite 27.2 |
| Reference | LG203 |
Geometries :
| Frame size | S | M | L | XL |
| Seat tube (mm) | 460 | 490 | 520 | 550 |
| Top tube (mm) | 529 | 550 | 571 | 592 |
| Base length (mm) | 425 | 425 | 425 | 425 |
| Steering bushing (mm) | 100 | 125 | 150 | 180 |
| Steering angle (°) | 69.5 | 71.1 | 72.5 | 72.5 |
| Seat tube angle (°) | 72.5 | 72.5 | 72.5 | 72.5 |
| Satck (mm) | 518 | 547 | 576 | 604 |
| Reach (mm) | 366 | 378 | 390 | 402 |
MORE INFORMATION
See all our Gravel Bikes.
Features
| Manufacturer Weight (g) | 10100 |
| Gender |
Women Men |
| Wheel Size | 700mm |
| Groupset | Shimano GRX |
