Cube Aim SLX Hardtail MTB Shimano Alivio/Altus 9S 29'' White Blue
Cube Aim SLX Hardtail MTB Shimano Alivio/Altus 9S 29'' White Blue
Cube Aim SLX Hardtail MTB Shimano Alivio/Altus 9S 29'' White Blue
Cube Aim SLX Hardtail MTB Shimano Alivio/Altus 9S 29'' White Blue
Cube Aim SLX Hardtail MTB Shimano Alivio/Altus 9S 29'' White Blue
Cube Aim SLX Hardtail MTB Shimano Alivio/Altus 9S 29'' White Blue
Cube Aim SLX Hardtail MTB Shimano Alivio/Altus 9S 29'' White Blue
Cube Aim SLX Hardtail MTB Shimano Alivio/Altus 9S 29'' White Blue
Cube Aim SLX Hardtail MTB Shimano Alivio/Altus 9S 29'' White Blue
Cube Aim SLX Hardtail MTB Shimano Alivio/Altus 9S 29'' White Blue

They love it!

★★★★★
★★★★★
5 Reviews
Cube
★★★★★
★★★★★
- 5 Reviews

Cube Aim SLX Hardtail MTB Shimano Alivio/Altus 9S 29'' White Blue Cube

€0.00

€699.99

€699.99

€699.99

€699.99

Frame size / rider height

Size Guide

Choose your option

S / 161-170 cm

Out of stock

M / 169-178 cm

Out of stock

L / 177-186 cm

Out of stock

XL / 185-197 cm

Out of stock

XXL / 196-203 cm

Out of stock

Non available

We will contact you by e-mail when this item is back in stock.

Choose an option

Non available

We will contact you by e-mail when this item is back in stock.

Choose an option

Non available

We will contact you by e-mail when this item is back in stock.

Choose an option

Non available

We will contact you by e-mail when this item is back in stock.

Choose an option

Non available

We will contact you by e-mail when this item is back in stock.

Choose an option

similar products

Description

What size do you need?


Choosing the right sized bike depends on the type of bike, your height, your riding style, and your preference. A correct fitting bike will be more comfortable, more efficient and more fun to ride

Measure yourself accurately

To get started, measure your height and use the size chart available on each product description.

What to do if you are in between bike sizes?

If you are on the edge of two different bike sizes, don't worry, you'll probably be ok on either size (rather than thinking that one size will be awful and the other will fit). Indeed, bikes are adjustable: the seatpost can slide up and down, the saddle can move backwards and forwards and you can even switch out parts like the stem for different sized ones to help the bike fit better.

Finding out whether or not you should pick a bigger or a smaller frame is sometimes as simple as personal preference, but there are a few simple ways to work out which might suit best:
  • If you’re flexible, you might prefer a shorter head tube, so the smaller size might work out better for you. You can use a longer stem to make the reach more comfortable.
  • On a bigger bike, the reach to the handlebars will be longer. This means that if you have proportionally longer arms, you might be more comfortable on a bigger frame.

Still confused? Contact us
Buying guide

Please note that specifications are subject to change without notice, based on component availability and other factors.

Beauty is more than skin deep: the Cube Aim's sleek looks are thanks to its Smooth Welded head tube and seat tube junctions. It incorporates a threaded bottom bracket and internal cable routing for long-lasting service and simple maintenance. There's even a flat disc mount that integrates seamlessly with our kickstand mount, and integrated mounting points for ACID mudguards and carrier. Updated geometry includes a lower top tube for more confident handling, and there's plenty of room to run wide, grippy and comfortable 2.25 in tyres. Our SizeSplit system has an expanded range, too, so however tall you are there'll be an Aim that fits perfectly.

You know that saying, "power is nothing without control"? Well, that's why we gave the Cube Aim SLX 100 mm of smooth, RockShox-flavoured bump-swallowing travel – with lockout. Combined with strong hydraulic disc brakes, a tapered head tube and tenaciously grippy 2.25in tires, it's the best way of ensuring you're always in full control, wherever your curiosity takes you. Wide-range 2x9 gears put the ideal ratio for any route at your fingertips, and the frame's even ready for a future dropper post upgrade. What's holding you back?

Main features:

  • Aluminium Lite frame, AMF (Advanced Mechancial Forming).
  • Shimano Alivio/Altus 2x9-speed drivetrain.
  • Shimano MT200/UR300 hydraulic disc brakes, 160/160 mm.

Features:

Frame Aluminium: Aluminium Lite, AMF, Double Butted, Internal Cable Routing, Tapered Head Tube, Flat Mount Brake, SIC Mount, FM Kickstand Mount, Width tires maximum: 58 mm
Fork RockShox Judy Silver TK Coil, Lockout, 100 mm travel
Shifters Shimano Altus SL-M2010-9R, Rapidfire-Plus, 2x9-speed
Front Derailleur Shimano Altus FD-M2020, Top Swing, 31.8 mm Clamp
Rear Derailleur Shimano Alivio RD-M3100-SGS, 9-speed
Cassette Shimano CS-HG201, 11-36T
Chain KMC X9
Crankset Shimano FC-MT101, 36/22T
Bottom Bracket Thun Paso-ML, 73 mm BSA
Brakes Shimano BR-MT200/UR300, Hydr. Disc Brake, PM/FM (160/160)
Wheelset Rims: Cube ZX20, 32H, Disc / Hubs: Shimano TX505, QR, Centerlock
Tires Schwalbe Smart Sam, Active, 29 x 2.25"
Handlebar Cube Rise Trail Bar, 680 mm
Grips Acid React
Stem Cube Performance Stem Race, 31.8 mm, 6°
Headset Cube FPH868, Semi-Integrated
Saddle Natural Fit Venec Lite
Seatpost Cube Performance Post, 27.2 mm
Pedals Acid PP MTB
Weight 13.8 kg
Weight Limit 115 kg: the maximum system weight consists of the bike, rider and equipments
Color white´n´blue´n´red
Reference 601510

Geometries:

Frame Size XS S M L XL XXL
Frame Size (inches) 14 16 18 20 22 24
Wheel Size (inches) 27.5 27.5 29 29 29 29
Seat Tube (mm) 340 370 420 470 515 560
Top Tube (mm) 555 575 595 615 635 655
Chain Stays (mm) 427 427 450 450 450 450
Head Tube Length (mm) 108 111 111 122 142 157
Head Tube Angle (°) 68.5 68.5 68.5 68.5 68.5 68.5
Seat Tube Angle (°) 74 73.5 73.5 73.5 73.5 73.5
Wheelbase (mm) 1068 1082 1125 1146 1168 1190
Stack (mm) 595 598 627 637 656 670
Reach (mm) 384 398 409 426 441 457
Stem Length (mm) 50 50 60 60 70 70
