Description
What size do you need?
Choosing the right sized bike depends on the type of bike, your height, your riding style, and your preference. A correct fitting bike will be more comfortable, more efficient and more fun to ride
Measure yourself accurately
To get started, measure your height and use the size chart available on each product description.
What to do if you are in between bike sizes?
If you are on the edge of two different bike sizes, don't worry, you'll probably be ok on either size (rather than thinking that one size will be awful and the other will fit). Indeed, bikes are adjustable: the seatpost can slide up and down, the saddle can move backwards and forwards and you can even switch out parts like the stem for different sized ones to help the bike fit better.
Finding out whether or not you should pick a bigger or a smaller frame is sometimes as simple as personal preference, but there are a few simple ways to work out which might suit best:
- If you’re flexible, you might prefer a shorter head tube, so the smaller size might work out better for you. You can use a longer stem to make the reach more comfortable.
- On a bigger bike, the reach to the handlebars will be longer. This means that if you have proportionally longer arms, you might be more comfortable on a bigger frame.
Still confused? Contact us
| Please note that specifications are subject to change without notice, based on component availability and other factors. |
Always fast. Short distances. Long distances. On trails. On trial roads. Climbing. Downhill. It's what you're looking for in a dual XC and marathon bike. The Nº1 frame for the World Cup with David Valero and the BH Coloma team.
For the best balance between aggressiveness and stability.
Longer reach, 68º /67º steering angle and short 430 mm chainstays preserve agility on ascents and descents
Like all high-end BH frames, the Lynx Race is designed on the basis of HCIM (Core Internal Molding) carbon molding technology, which reduces frame and pushrod weight to a minimum, while using a greater quantity of high-modulus fibers to achieve a weight of 1,850 grams including shock absorber.
A new, oversized main suspension axle with self-centering bearings increases torsional rigidity by 30%.
Thanks to the use of the "Metric" standard, the Lynx Race offers 100 or 120 mm of travel, while maintaining the same level of antisquat, which guarantees pedaling efficiency, and brake-squat, which ensures optimal braking.
Your eyes see potholes and obstacles. But your body doesn't notice them. They're there, but not to slow you down. Now the obstacles are there to have fun with.
Take on that trail sitting on the saddle and feel how the wheel traces the terrain while you can concentrate on pedaling harder and harder.
Main features:
- Lynx Race carbon/aluminium frame.
- Shimano SLX 1x12-speed transmission
- Shimano MT410 hydraulic disc brakes, 180/160 mm
Features:
| Frame | Carbon: Lynx Race Carbon, PC Layup Front, Alloy7005 Rear Triangle |
| Forks | Rock Shox Recon RL Remote 100mm |
| Shock absorber | Rock Shox Deluxe,190x40,CM,DRM,40x8Aircan NO bushing |
| Derailleur lever | Shimano SLX 7100, 1x12-speed |
| Rear derailleur | Shimano SLX 7100, 12-speed |
| Cassette | Shimano Deore 6100, 10-51T |
| Chain | Shimano SLX |
| Crankset | Shimano MT510, 175 mm |
| Brakes | Shimano MT410, 180/160 mm |
| Wheelset | Race Face Affect TLR, 27mm, 32H, Shimano MT400/412 hubs |
| Tires | Front: Maxxis Ardent EXO Maxxis Ardent EXO 2.25 / Rear: Maxxis Ikon EXO 2.25 |
| Handlebars | BH Lite Flat 780mm |
| Grips | BH SL Lock On |
| Stem | BH SL 80mm, 31,8mm, +/-6 |
| Headset | Acros ICR 36/45, Block Lock 160 |
| Saddle | Prologo R4 |
| Seat post | BH Lite 31.6mm 420mm |
| Reference | DX305 |
Geometries :
| Frame size | S | M | L | XL |
| Seat tube (mm) | 400 | 440 | 480 | 520 |
| Top tube (mm) | 571 | 580 | 605 | 625 |
| Base length (mm) | 430 | 430 | 430 | 430 |
| Steering bushing (mm) | 90 | 95 | 110 | 125 |
| Steering angle (°) | 68 | 68 | 68 | 68 |
| Seat tube angle (°) | 76 | 75.8 | 75.8 | 75 |
| Wheelbase (mm) | 1096 | 1131 | 1151.5 | 1168 |
| Stack (mm) | 575 | 580 | 595 | 610 |
| Reach (mm) | 410 | 436 | 456 | 472 |
MORE INFORMATION
See our best MTBs.
Features
| Frame material | Alloy / Carbon |
| Groupset | Shimano SLX |
