Description
What size do you need?
Choosing the right sized bike depends on the type of bike, your height, your riding style, and your preference. A correct fitting bike will be more comfortable, more efficient and more fun to ride
Measure yourself accurately
To get started, measure your height and use the size chart available on each product description.
What to do if you are in between bike sizes?
If you are on the edge of two different bike sizes, don't worry, you'll probably be ok on either size (rather than thinking that one size will be awful and the other will fit). Indeed, bikes are adjustable: the seatpost can slide up and down, the saddle can move backwards and forwards and you can even switch out parts like the stem for different sized ones to help the bike fit better.
Finding out whether or not you should pick a bigger or a smaller frame is sometimes as simple as personal preference, but there are a few simple ways to work out which might suit best:
- If you’re flexible, you might prefer a shorter head tube, so the smaller size might work out better for you. You can use a longer stem to make the reach more comfortable.
- On a bigger bike, the reach to the handlebars will be longer. This means that if you have proportionally longer arms, you might be more comfortable on a bigger frame.
Still confused? Contact us
| Please note that specifications are subject to change without notice, based on component availability and other factors. |
Modern trail bikes are used for an impressive variety of rides. Some riders use them to climb thousands of meters on huge rides, others weave in and out of bike parks and jumps during their daily adventures. The Orbea Occam LT is the wilder side of Occam thanks to more aggressive geometry, Fox 36 forks, and 10 mm more travel. Occam LT is hugely capable but also more versatile than a full-on enduro bike with efficient pedaling for all-day rides. The sturdy Fox 36 fork slackens the Occam LT’s head angle by 0.5º, giving it an even more self assured stance.
Instead of using a less-efficient "shock tunnel," the Occam offsets the shock to the left side of the frame, allowing the right-side support to be more central and more efficiently deal with the suspension forces acting on the front triangle. This solution enables us to tune the stiffness of this high-stress area without adding unnecessary weight.
We use the most technologically advanced carbon construction available to make the most sophisticated frame possible. A complex and painstaking process with results you will appreciate in the saddle. Orbea Monocoque Race (OMR) carbon frames add high modulus and high strength fibers to a standard layup to improve stiffness-to-weight ratios. Bladder molding with EPS forms and PU headtube and bottom bracket inserts stop wrinkling and unconformities in critical zones, allowing less carbon to be used while maintaining strength.
Main features:
- The wilder side of the Orbea Occam.
- OMR (Orbea Monocoque Race) carbon frame.
- 150 mm front and rear travel.
- Shimano XT 1x12-speed drivetrain.
- Shimano XT M8120 hydraulic disc brakes.
Features:
| Frame | Carbon: Orbea Occam OMR, Concentric Boost 12x148 mm rear axle, Pure Trail geometry, Internal cable routing, Asymmetric design, 29" wheels |
| Fork | Fox 36 Float Factory, Grip2, QR15x110 mm, Kashima, 150 mm travel |
| Rear Shock | Fox DHX Factory 2-Position custom tune 210x55 mm |
| Shifter | Shimano XT M8100, I-Spec EV, 1x12-speed |
| Rear Derailleur | Shimano XT RD-M8100-SGS, Shadow RD+, 12-speed |
| Cassette | Shimano Deore XT CS-M8100-12, 10-51T |
| Chain | Shimano Deore CN-M6100 |
| Crankset | Shimano XT M8100, 32T |
| Brakes | Shimano XT M8120, Hydr. Disc Brake |
| Wheelset | Race Face Turbine R 30, TLR, 29" |
| Tires | Front: Maxxis Minion DHF, FB, 60 TPI, 3CMaxxTerra, Exo, TLR, 29x2.50" / Rear: Maxxis Dissector, 60 TPI, 3CMaxxTerra, Exo, TLR, 29x2.40" |
| Handlebar | Race Face Next R 35, Rise 20 mm, Width 780 mm |
| Stem | Race Face Aeffect R, 35 mm interface |
| Headset | Acros Alloy 1-1/8 - 1-1/2" Integrated |
| Saddle | Fizik Taiga, S-alloy rail |
| Seatpost | OC2 Dropper, 31.6 mm / Shimano SL-MT500-IL I-Spec EV Remote |
| Weight | --- |
| Color | C2 - Black (Matt) |
| Reference | M259 |
Geometries:
| Frame Size | S | M | L | XL |
| Seat Tube (mm) | 381 | 419 | 457 | 508 |
| Top Tube (mm) | 565 | 592 | 619 | 649 |
| Chain Stays (mm) | 440 | 440 | 440 | 440 |
| Head Tube Length (mm) | 95 | 105 | 120 | 140 |
| Head Tube Angle (°) | 65.5 | 65.5 | 65.5 | 65.5 |
| Seat Tube Angle (°) | 76.5 | 76.5 | 76.5 | 76.5 |
| Wheelbase (mm) | 1165 | 1194 | 1224 | 1259 |
| Stack (mm) | 604 | 613 | 627 | 646 |
| Reach (mm) | 425 | 450 | 474 | 500 |
MORE INFORMATION
See all the Orbea Occam
See our best MTBs.
Features
| Frame material | Carbon |
| Groupset | Shimano Deore XT |
