BH Atom 29 Shimano Alivio 9V 500 Wh 29'' Semi-Rigid Electric Bike Black / Red
BH
★★★★★
★★★★★
Description
What size do you need?
Choosing the right sized bike depends on the type of bike, your height, your riding style, and your preference. A correct fitting bike will be more comfortable, more efficient and more fun to ride
Measure yourself accurately
To get started, measure your height and use the size chart available on each product description.
What to do if you are in between bike sizes?
If you are on the edge of two different bike sizes, don't worry, you'll probably be ok on either size (rather than thinking that one size will be awful and the other will fit). Indeed, bikes are adjustable: the seatpost can slide up and down, the saddle can move backwards and forwards and you can even switch out parts like the stem for different sized ones to help the bike fit better.
Finding out whether or not you should pick a bigger or a smaller frame is sometimes as simple as personal preference, but there are a few simple ways to work out which might suit best:
- If you’re flexible, you might prefer a shorter head tube, so the smaller size might work out better for you. You can use a longer stem to make the reach more comfortable.
- On a bigger bike, the reach to the handlebars will be longer. This means that if you have proportionally longer arms, you might be more comfortable on a bigger frame.
Still confused? Contact us
| Please note that specifications are subject to change without notice, based on component availability and other factors. |
If you're looking for an electric bike with an integrated battery, the geometry of a classic bike and great autonomy, the BH Atom 29 is the bike you're looking for.
The relative position of the lightest elements of the system (motor and battery) allows for a low center of gravity, guaranteeing a responsive and stable bike without having to sacrifice its geometry. The Full Suspension range incorporates the Split Pivot system, which allows the three forces acting on a bike to be controlled independently: pedaling, braking and suspension.
Its "TS System", patented by BH, integrates the battery into the down tube in a simple and minimalist way. It incorporates a color LCD screen, with over 40 configurable functions and ergonomic remote control.
Product advantages:
- Aluminum MTB frame.
- Shimano Alivio 1x9 speed transmission.
- Shimano MT200 hydraulic disc brakes, 180/180 mm
- BH motor with a 500 Wh battery for a range of up to 105 km.
Details :
| Frame | Aluminum: MTB Alloy 29" Internal Cable Routing |
| Fork | SR Suntour XCM HLO 100mm |
| Motor | BH 1E-36V |
| Battery | 500 Wh |
| Screen | BH X Display Lite |
| Headset | Tapered |
| Stem | BH Ahead |
| Handlebars | BH MTB Alloy Riser 780mm |
| Handles | BH Perform W/ Ringlock |
| Derailleur shifter | Shimano Alivio, 1x9 speed |
| Rear derailleur | Shimano Alivio, 9 speed |
| Crankset | FSA 36 Teeth - 170 mm |
| Chain | Shimano HG53 |
| Cassette | Shimano CSHG201, 11-36 teeth, 9 speed |
| Brakes | Shimano MT200 180/180 mm |
| Saddle | Prologo Proxim W350 Stn |
| Seatpost | Alloy 31,6 |
| Wheels | Alloy Double Wall |
| Tires | Maxxis Forekaster TPI60 29 "X2,35 |
| Weight | --- |
| Colors | Black / Red |
Geometries :
| Frame size | S | M | L |
| Seat tube (mm) | 450 | 500 | 520 |
| Top tube (mm) | 604 | 623 | 647 |
| Base length (mm) | 470 | 470 | 470 |
| Header sleeve (mm) | 140 | 145 | 160 |
| Steering angle (°) | 69 | 69 | 69 |
| Seat tube angle (°) | 74 | 74 | 74 |
| Wheelbase (mm) | 696 | 710 | 733 |
| Stack (mm) | 657 | 662 | 676 |
| Reach (mm) | 409 | 427 | 443 |
MORE INFORMATION
See our best MTBs.
See the whole range of E-Bikes available.
Features
| Frame material | Alloy |
| Groupset | Shimano Alivio |
